| P
|
螺距 |
粗牙 |
| 细牙1 |
| 细牙2 |
| dk
|
最大值 |
| e
|
最小值 |
| h1
|
公称 |
| 最大值 |
| 最小值 |
| h
|
公称 |
| 最大值 |
| 最小值 |
| m
|
最小值 |
| SR
|
≈ |
| s
|
最大值 |
| 最小值 |
| t
|
≈ |
| 千件重(钢制)≈kg
|
|
|
| 0.7 |
0.8 |
1 |
1.25 |
1.5 |
1.75 |
2 |
2 |
2.5 |
| / |
/ |
/ |
1 |
1 |
1.5 |
1.5 |
1.5 |
2 |
| / |
/ |
/ |
/ |
1.25 |
1.25 |
/ |
/ |
1.5 |
| 6.5 |
7.5 |
9.5 |
12.5 |
16 |
18 |
21 |
23 |
28 |
| 7.66 |
8.79 |
11.05 |
14.38 |
17.77 |
20.03 |
23.35 |
26.75 |
32.95 |
| 5.6 |
6 |
7.5 |
8.9 |
10.5 |
13.5 |
15.5 |
16.5 |
21 |
| 5.85 |
6.25 |
7.85 |
9.25 |
10.9 |
13.9 |
15.9 |
16.9 |
21.5 |
| 5.35 |
5.75 |
7.15 |
8.55 |
10.1 |
13.1 |
15.1 |
16.1 |
20.5 |
| 9.6 |
10.5 |
12 |
14 |
18.1 |
22.5 |
26.4 |
27.5 |
35 |
| 9.9 |
10.85 |
12.35 |
14.35 |
18.5 |
22.9 |
26.8 |
27.9 |
35.5 |
| 9.3 |
10.15 |
11.65 |
13.65 |
17.7 |
22.1 |
26 |
27.1 |
34.5 |
| 2.9 |
4.4 |
4.9 |
6.44 |
8.04 |
10.37 |
12.1 |
14.1 |
16.9 |
| 2.5 |
3 |
3.5 |
4.6 |
5.8 |
6.8 |
7.8 |
8.8 |
10.8 |
| 7 |
8 |
10 |
13 |
16 |
18 |
21 |
24 |
30 |
| 6.78 |
7.78 |
9.78 |
12.73 |
15.73 |
17.73 |
20.67 |
23.67 |
29.16 |
| 0.5 |
0.5 |
0.8 |
0.8 |
0.8 |
1 |
1 |
1 |
1.2 |
| 1.4 |
1.55 |
3.3 |
5.3 |
10.1 |
18.3 |
26.1 |
37.1 |
111 |
|
